Inconel 718 Forged/Forging Parts/Pipes/Tubes/Sleeves/Bushings (UNS N07718, 2.4668, Alloy 718)

Home / Special Materials / Inconel 718 Forged/Forging Parts/Pipes/Tubes/Sleeves/Bushings (UNS N07718, 2.4668, Alloy 718)
  • Inconel 718 Forged/Forging Parts/Pipes/Tubes/Sleeves/Bushings (UNS N07718, 2.4668, Alloy 718)

    Product Description

    Inconel 718 is known for having incredible strength. In fact, Inconel 718 is almost twice as strong as Inconel 625, which is another Inconel alloy that continues to be in high demand for many industrial sectors. Inconel 718 can withstand immense pressure and possesses high resistance to corrosion from the elements, which includes prolonged exposure to saltwater and oxygen.

    Because of these characteristics, Inconel 718 is in high demand in many different sectors. Several industries that require superalloys include aircraft engines, commercial space applications, oil and gas, power generation, chemical and petrochemical processing and anywhere else there may be an application within a harsh environment.

    The type of Inconel 718, UNS N07718, 2.4668 forging/forged parts that we could do is as follows: Forged shaft, forged round bars, forged flanges, forging disks, forged tube sheets, forged gears, forged pipes, forged sleeves, forged blocks, forged rings, rolled rings, forged blocks and so on
    Any inquiries about Inconel 718 UNS N07718, 2.4668 forging/forged parts, please feel free to contact us. We are glad to quote the price for every client

    Element Proportion (Mass %)

    ALLOY (UNS) NI FE SI C S MG AL TI CR MO NB & TA CO P B CU
    N07718
    50.0 – 55.0
    BALANCE*
    0.35 MAX
    0.08 MAX
    0.015 MAX
    0.35 MAX
    0.20 – 0.80
    0.65 – 1.15
    17.0 – 21.0
    2.80 – 3.30
    4.75 – 5.50
    1.0 MAX
    0.015 MAX
    0.006 MAX
    0.006 0.30 MAX

    Inconel 718 Physical properties



    Density

    8.2 g/cm³

    Melting point

    1260-1340 °C



    Inconel 718 Alloy mechanical properties at room temperature



    Alloy

    Tensile strength
    Rm N/mm²

    Yield strength
    R P0. 2N/mm²

    Elongation
    A 5 %

    Brinell hardness
    HB

    Solution treatment

    965

    550

    30

    ≤363





    The characteristics of Inconel 718
    Good mechanical properties - tensile, fatigue and creep-rupture
    Yield tensile strength, creep, and rupture strength properties are exceedingly high
    Highly resistant to chloride and sulfide stress corrosion cracking
    Resistant to aqueous corrosion and chloride ion stress corrosion cracking
    High temperature resistant
    Age-hardenable with a unique property of slow aging response that permits heating and cooling during annealing without the danger of cracking.
    Excellent welding characteristics, resistant to post-weld age cracking


    Inconel 718 Typical application field as below:
         1 . The Organic chemical process parts contain chloride, especially in the use of acid chloride catalysts.
         2. The digester and bleachers are the use of paper pulp and paper making industry.
         3. Absorption tower, re-heater, gas import board, fan, blender, fair water fin, flue, and so on for use in flue gas desulfurization system.
         4. The equipment and parts in the use of acidic gas environments.
         5. Acetic acid and anhydride reaction generator
         6. Sulfur acid cooling
